Selected appliance
|
EAN code |
7630029432709 |
|
Predecessor’s article number |
2100600021 |
|
Controls |
dial |
|
Installation in floor unit |
Yes |
|
TopClean |
Yes |
|
Standard width |
60 cm |
|
Standard height |
60.0 cm |
|
Short model
|
Yes |
|
Front design |
White |
|
Handle |
white |
|
Cooking space |
Brillant enamel |
|
Drawer |
without Appliance drawer |
Display and operation
|
Display |
visual operating display (LED) |
|
Controls |
dial |
|
Lighting |
Halogen |
|
Number of lights |
1 |
Oven features
|
Number of insertion levels |
4 |
|
Panel height |
80 mm |
|
Installation in floor unit |
Yes |
|
Easy door cleaning |
by disassembling the door |
|
Premium Swiss Quality
|
Yes |
|
SoftClose
|
Yes |
|
SoftOpen |
Yes |
|
Combined operation |
Oven |
|
TopClean |
Yes |
|
Number of storable programmes
|
0 |
|
Cooking space volume |
69 l |
|
Max. temperature setting with top/bottom heat |
280 °C |
Service and interfaces
|
WLAN as standard |
802.11 b/g/n |
|
ZUG-eye |
Yes |
|
V-ZUG-Home
|
Yes |
|
Warranty |
2 years |
|
Interface
|
WLAN and Bluetooth |
Accessories included
| Product |
Quantity |
| Baking tray TopClean 52, 56 Liter (370 x 430) (K44006) |
1 |
| Wire shelf, Chrome steel (K44119) |
1 |
Also available with/as (*)
| Standard width |
55 cm |
| Standard height |
76.2 cm |
| Front design |
Nero |
| Handle |
Nero |
| Drawer |
Appliance drawer |
(*) Not all combinations are available. Ask your retailer for advice.
-
Top & bottom heat Eco programme
-
Top/bottom heat
-
Humid top/bottom heat
-
Bottom heat
-
Top heat
Technical data
Dimensions
|
Niche height |
590 mm |
|
Max. niche height |
590 mm |
|
Niche width |
560 mm |
|
Max. niche width |
568 mm |
|
Niche depth |
550 mm |
|
Appliance height |
598 mm |
|
Max. appliance height |
599 mm |
|
Appliance width |
596 mm |
|
Appliance depth |
569 mm |
|
Depth of appliance when door is open |
483 mm |
|
Empty weight |
35 kg |
Energy
|
Automatic shut-off consumption with network switched on |
1 W |
|
Energy efficiency rating |
A |
|
Energy consumption - conventional cooking |
0.8 kWh |
|
Type of connection (1) |
400 V 2~ |
|
Frequency (1) |
50 Hz |
|
Nominal power, oven |
2.3 kW |
|
Connected loads (1) |
2.3 kW |
|
Fuse protection (1) |
6 A |
|
Plug type |
socket |
The following accessories go with this device
Art. no. K48135
Art. no. K38134
Art. no. K38129
Art. no. K50572
Art. no. K44006
Art. no. K48128
Art. no. K37158
Art. no. K37159
Art. no. 1060456
Art. no. 1067231
Art. no. 1064718
Art. no. 1064716
Art. no. 1064717
Art. no. 1064723
Art. no. 1064720
Art. no. 1064722
Art. no. K27622
Art. no. K27626
Art. no. K27621
Art. no. K34527
Art. no. K34528
Art. no. K34529
Art. no. K44119
