Selected appliance
|
EAN code |
7640138337567 |
|
Controls |
External operation via cooker |
|
Standard width |
60 cm |
|
Front design |
BlackDesign |
|
Frame |
Chrome frame |
Display and operation
|
Display |
visual operating display (LED) |
|
Controls |
External operation via cooker |
|
Languages in display
|
- |
Hob features
|
Hob category |
Quicklight |
|
Residual heat indicator |
Yes |
|
Cooking zones |
4 |
|
Power levels |
6 |
|
Heating technology |
radiation cooking zones |
Service and interfaces
Also available with/as (*)
| Frame |
Oversize mounting frame, Flush-fitting |
(*) Not all combinations are available. Ask your retailer for advice.
Technical data
Dimensions
|
Appliance height |
51 mm |
|
Appliance width |
584 mm |
|
Appliance depth |
514 mm |
|
Appliance corner radius |
8 mm |
|
Support size width |
560 mm |
|
Max. support size width |
560 mm |
|
Support size depth |
490 mm |
|
Max. support size depth |
490 mm |
|
Installation height when surface-mounted |
47.5 mm |
|
Cut-out width when surface-mounted |
560 mm |
|
Max. cut-out width when surface-mounted |
560 mm |
|
Cut-out depth when surface-mounted |
490 mm |
|
Max. cut-out depth when surface-mounted |
490 mm |
|
Empty weight |
7.5 kg |
|
Cooking zone 1 position |
front left |
|
Cooking zone 1 dimensions |
18 cm |
|
Cooking zone 2 position |
rear left |
|
Cooking zone 2 dimensions |
18 cm |
|
Cooking zone 3 position |
rear right |
|
Cooking zone 3 dimensions |
21 cm |
|
Cooking zone 4 position |
front right |
|
Cooking zone 4 dimensions |
14 cm |
Energy
|
Cooking zone 1 max. power |
1800 W |
|
Cooking zone 2 max. power |
1800 W |
|
Cooking zone 3 max. power |
2300 W |
|
Cooking zone 4 max. power |
1200 W |
|
Type of connection (1) |
400V 2~ |
|
Frequency (1) |
50Hz |
|
Connected loads (1) |
7.1 kW |
|
Fuse protection (1) |
20 A |
|
Plug type |
cable |
