Selected appliance
| Article no. |
6202000203 + 1046987 |
|
EAN code |
7630029426760 + 7630029429037 |
|
Telescopic casing |
Long |
|
Controls |
push buttons |
|
Standard width |
70 cm |
|
Front design |
ChromeClass |
|
Installation method |
Wall hood |
|
Recirculation air filter |
Standard activated charcoal filter |
Display and operation
|
Controls |
push buttons |
|
Fan power level display |
Yes |
|
Lighting |
LED |
|
Number of lights |
2 |
Range hood features
|
Grease filter cleaning indicator
|
Yes |
|
Activated charcoal filter saturation indicator
|
Yes |
|
Telescopic casing |
Long |
|
Power levels |
3 + i |
|
Remote control |
Optional, available as accessory |
|
Dimming lights
|
Yes |
|
Fleece grease filter |
2 |
|
Non-return flap, integrated/attached |
included |
Service and interfaces
Also available with/as (*)
| Telescopic casing |
Standard |
| Standard width |
60 cm, 90 cm |
| Recirculation air filter |
Long-life activated charcoal filter |
(*) Not all combinations are available. Ask your retailer for advice.
-
Dimming lights
-
Grease filter cleaning indicator
-
Activated charcoal filter saturation indicator
-
recirculation air
-
Intensive setting
-
Automatic after-running time
Technical data
Dimensions
|
Device height exhaust air |
830 mm |
|
Device height exhaust air maximum |
1160 mm |
|
Device height recirculation air |
910 mm |
|
Device height recirculation air maximum |
1260 mm |
|
Front height |
60 mm |
|
Appliance width |
698 mm |
|
Appliance depth |
470 mm |
|
Max. appliance depth |
470 mm |
|
Empty weight |
17.7 kg |
Energy
|
Energy efficiency rating |
A+ |
|
Annual energy consumption |
41.7 kWh |
|
Lighting efficiency rating |
A |
|
Fluid dynamic efficiency |
35 |
|
Fluid dynamic efficiency rating |
A |
|
Type of connection (1) |
220-240V~ |
|
Nominal lighting output (quantity x W) |
2 x 1 W |
|
Frequency (1) |
50Hz |
|
Connected loads (1) |
0.27 kW |
|
Fuse protection (1) |
10 A |
|
Plug type |
CH Typ 12 |
|
Connection cable |
1.2 m |
Additional data
|
Light colour in kelvin
|
3000 K |
|
Exhaust air connection (diameter) |
150 mm |
|
Lighting efficiency |
109 |
|
Illumination on cooking surface |
240 lux |
|
Grease absorption capacity rating |
B |
|
Extracted air output, intensive setting |
700 m³/h |
|
Extracted air output, max. setting |
580 m³/h |
|
Extracted air output, min. setting |
300 m³/h |
|
Recirculation air output, intensive setting |
440 m³/h |
|
Recirculation air output, max. setting |
420 m³/h |
|
Recirculation air output, min. setting |
280 m³/h |
|
Extracted air noise output, intensive setting |
69 dB(A) |
|
Extracted air noise level, max. setting |
66 dB(A) |
|
Extracted air noise output, min. setting |
52 dB(A) |
|
Recirculation air noise output, intensive setting |
76 dB(A) |
|
Recirculation air noise output, max. setting |
75 dB(A) |
|
Recirculation air noise output, min. setting |
69 dB(A) |
|
Connection for fresh air/exhaust air flap |
Yes |
|
Motor(s) |
1 |
|
Motor output |
270 W |
