Selected appliance
|
EAN code |
7630029426203 |
|
Predecessor’s article number |
3102300202 |
|
Controls |
TouchControl |
|
Standard width |
30 cm |
|
Front design |
BlackDesign |
|
Frame |
DualDesign |
Display and operation
|
Display |
Digital display |
|
Controls |
TouchControl |
|
Operating time |
Yes |
|
Languages in display
|
- |
|
Button sound (on/off) |
Yes |
Hob features
|
Hob category |
Toptronic |
|
Operating time with shut-down function
|
Yes |
|
Residual heat indicator |
Yes |
|
Timer |
Yes |
|
Cooking zones |
2 |
|
Power levels |
9 |
|
EcoStandby
|
Yes |
|
Heating technology |
radiation cooking zones |
Service and interfaces
-
Childproof look
-
Automatic warm-up function
Other settings
|
Safety package
|
Yes |
|
Pan detection
|
No |
Technical data
Dimensions
|
Cut-out height |
8.5 mm |
|
Cut-out radius |
5 mm |
|
Appliance height |
47.7 mm |
|
Appliance width |
281 mm |
|
Appliance depth |
501 mm |
|
Appliance corner radius |
1.5 mm |
|
Support size width |
270 mm |
|
Max. support size width |
270 mm |
|
Support size depth |
490 mm |
|
Max. support size depth |
490 mm |
|
Installation height when flush-fitted |
47.5 mm |
|
Installation height when surface-mounted |
43.5 mm |
|
Cut-out width when flush-mounted |
287 mm |
|
Cut-out width when surface-mounted |
270 mm |
|
Max. cut-out width when surface-mounted |
270 mm |
|
Cut-out depth when flush-mounted |
507 mm |
|
Cut-out depth when surface-mounted |
490 mm |
|
Max. cut-out depth when surface-mounted |
490 mm |
|
Empty weight |
5 kg |
|
Cooking zone 1 position |
front |
|
Cooking zone 1 dimensions |
14 cm |
|
Cooking zone 2 position |
rear |
|
Cooking zone 2 dimensions |
12/18 cm |
Energy
|
Cooking zone 1 max. power |
1200 W |
|
Cooking zone 2 max. power |
1800 W |
|
Type of connection (1) |
220-240 V~ |
|
Frequency (1) |
50-60 Hz |
|
Connected loads (1) |
3 kW |
|
Fuse protection (1) |
16 A |
